73.6V 40Ah LFP battery for logistics robot

Product Introduction

Engineered exclusively as a 73.6V 40Ah LFP Battery for Logistics Robot, this lithium iron phosphate (LFP) power pack is optimized for the dynamic demands of automated logistics robots—from AGV material transporters to high-speed sorting robots. With a 73.6V nominal voltage, 40Ah high-density capacity, and a rugged SPCC enclosure, this 73.6V 40Ah LFP Battery for Logistics Robot stands out with 2.94kWh total energy and 240A peak discharge: it enables logistics robots to handle 500+ kg payloads and operate continuously for 12+ hours per charge. Unlike generic robot batteries, its 23S cell configuration and IP54 protection are tailored to indoor warehouse dust, frequent vibration, and occasional liquid splashes—making it the reliable core for high-frequency logistics workflows.

Technical Specifications

Table: 73.6V 40Ah LFP Battery for Logistics Robot Core Parameters

Parameter	Details (Tailored for Logistics Robots)
Cell Type	LFP 40Ah
Cell Cycle Life	≥3000 cycles (100% DOD) – reduces logistics robot battery replacement frequency
System Cycle Life	≥2500+ cycles (100% DOD)
Cell Certification	UN38.3
Nominal Capacity	40AH (1P) – supports 12+ hours of logistics robot continuous operation
Nominal Voltage	73.6V (23S)
Working Voltage Range	57.5V-89.95V
Total Energy	2.94kWh – powers 12+ hours of AGV material handling tasks
Weight	≈29.5kg
Normal Charging Current	≤120A – fast recharge between logistics shifts
Peak Charging Current	≤150A
Continuous Discharge Current	≤180A – sustains stable performance for sorting logistics robots
Peak Discharge Current	≤240A – handles 500+ kg payloads for warehouse logistics robots
Operating Temperature	Charge: 0℃-45℃; Discharge: -15℃-60℃ – adapts to temperature-variable logistics warehouses
Communication	CAN/UART/485 – integrates with logistics robot fleet management systems
Casing Material	SPCC – resists impacts from cargo in logistics transport
Protection Grade	IP54 – dust/water-resistant for indoor logistics environments
Plug Type	FSP202008CC-M8BY – secure connection for high-power logistics robots
Dimensions (L×W×H)	520mm×340mm×168mm – fits standard AGV logistics robot chassis
Application	AGV Material Handling Robots, Warehouse Sorting Logistics Robots, Indoor Logistics Transport Robots

Core Advantages of 73.6V 40Ah LFP Battery for Logistics Robot

1. 12+ Hour Runtime for Uninterrupted Logistics Workflows
The 73.6V 40Ah LFP Battery for Logistics Robot delivers 2.94kWh total energy:It powers warehouse sorting logistics robots through 12+ hours of continuous parcel sorting (4000+ units per shift) without mid-task recharging.For AGV material handling robots, this capacity supports 8+ hours of cross-warehouse cargo transfers (300+ pallet moves).

2. 240A Peak Discharge for Medium-Heavy Logistics Loads
Tailored for logistics robot payload needs:240A peak discharge enables indoor logistics transport robots to lift 500+ kg bulk cargo—critical for manufacturing warehouse material flows.180A continuous discharge sustains stable speed during frequent start/stop cycles (common in sorting logistics yards).

3. IP54 Protection for Indoor Logistics Environments
Built for warehouse logistics scenarios:IP54 dust/water-resistant rating shields the battery from warehouse dust accumulation and occasional liquid spills (e.g., cleaning solutions)—no performance loss in typical indoor logistics workspaces.

4. ≥2500 System Cycles for Cost-Efficient Logistics Fleets
Optimized for high-frequency logistics use:≥2500 system cycles mean this 73.6V 40Ah Logistics Robot Battery lasts 1.5x longer than standard alternatives. For a 15-unit AGV logistics fleet, this cuts 3-year battery replacement costs by 60%.

5. Multi-Protocol Communication for Logistics Fleet Coordination
Syncs with logistics operations:CAN/UART/485 communication transmits real-time battery data (SOC, temperature) to logistics robot management platforms. Managers can schedule charging during off-peak hours, minimizing workflow downtime.

Application Scenarios

1. AGV Material Handling Robots
The 73.6V 40Ah LFP Battery for Logistics Robot powers 500+ kg cargo lifts. 240A peak discharge handles bulk material transfers, and IP54 protection resists warehouse debris.

2. Warehouse Sorting Logistics Robots

It suits 12+ hours of non-stop parcel sorting. 2.94kWh energy covers full-shift tasks, and long cycle life reduces maintenance for high-volume e-commerce logistics.

3. Indoor Logistics Transport Robots

It energizes 8+ hours of cross-warehouse cargo delivery. Wide temperature adaptability works in cooled/heated warehouse zones, and compact dimensions fit standard robot chassis.
