48V 18Ah LiFePO4 Battery
48V 18Ah LiFePO4 Battery for AGV with CAN RS485 BMS
48V 18Ah LiFePO4 Battery for AGV with CAN RS485 BMS
48V 18Ah LiFePO4 Battery for AGV with CAN RS485 BMS
48V 18Ah LiFePO4 Battery for AGV with CAN RS485 BMS
48V 18Ah LiFePO4 Battery for AGV with CAN RS485 BMS

48V 18Ah LiFePO4 Battery for AGV with CAN RS485 BMS

Category

48V 18Ah LiFePO4 Battery for AGV delivers 48V 18Ah power, CAN RS485 communication, and LFP safety—ideal for warehouse AGVs, factory material carts, and cold-chain automated vehicles.

  • Nominal Voltage：48V
  • Rated Capacity：18Ah
  • Actual Voltage：48V
  • Charging Voltage：54.75V
  • Minimum Discharge Voltage：42V
  • Nominal Discharge Current：Max 30A continuous discharge
  • Nominal Charging Current：Max 18A continuous charge
  • Discharge Protection：<42V
  • Overtemperature Protection：>65℃
  • Operating Temperature：-10～60℃
  • Weight: 7KG
  • Dimension：212mm(L)*175mm(W)*164mm(H)
  • Communication Interface：CAN, RS485

For More Robot Battery Solution Service, please Contact Us for details!

Quote Now
Send Email

48V 18Ah LiFePO4 Battery for AGV: Dual CAN RS485 BMS for Automated Guided Vehicles

Product Introduction

Engineered as a 48V 18Ah LiFePO4 Battery for AGV, this lithium iron phosphate (LFP) solution is purpose-built for automated guided vehicles. Featuring 48V nominal voltage, 18Ah capacity, and integrated CAN/RS485 BMS, this AGV-Tailored 48V 18Ah LFP Battery enables real-time fleet monitoring, supports 30A continuous discharge for heavy loads, and operates reliably in -10~60℃ environments. Unlike standard batteries, it combines LFP’s inherent safety, dual communication protocols, and precise BMS—making it the go-to power source for warehouse AGVs, factory material transporters, and cold-chain automation.

Technical Specifications

Table: 48V 18Ah LiFePO4 Battery for AGV Core Parameters

Parameter Details
Chemistry Lithium Iron Phosphate (LiFePO4 / LFP)
Nominal Voltage 48V
Rated Capacity 18Ah
Charging Voltage 54.75V
Discharge Cut-off Voltage 42V
Max Discharge Current 30A (Continuous)
Max Charging Current 18A (Continuous)
Operating Temperature -10~60℃
Dimensions 212mm(L)×175mm(W)×164mm(H)
Communication Interfaces CAN, RS485 (For AGV Fleet Management)
BMS Features Over-current, Over-voltage, Short Circuit, Over-temperature Protection
Application Warehouse AGVs, Factory Material AGVs, Cold-Chain Automated Vehicles

Core Advantages of 48V 18Ah LiFePO4 Battery for AGV

1. Dual CAN RS485 Communication for AGV Fleet Intelligence

“The 48V 18Ah LiFePO4 Battery for AGV supports CAN and RS485, enabling AGVs to transmit battery health, SOC, and temperature data to warehouse management systems. This allows for predictive maintenance, route optimization, and seamless integration into automated logistics workflows—critical for minimizing downtime in 24/7 material handling operations.”

2. LFP Chemistry: Safety & Longevity for AGV Operations

“Leveraging lithium iron phosphate (LFP) technology:
  • Inherently Safe: LFP’s thermal stability eliminates thermal runaway risks, ideal for AGVs operating in high-traffic warehouse environments.
  • 2000+ Cycle Life: Endures thousands of charge-discharge cycles, reducing replacement costs for AGV fleets running round-the-clock in factories and logistics hubs.”

3. 30A High Discharge for AGV Heavy-Load Tasks

“With 30A continuous discharge, this 48V 18Ah LFP Battery for AGV powers AGVs transporting heavy pallets, lifting loads, or navigating inclines. It handles peak demands like simultaneous motor operation and sensor data transmission, ensuring uninterrupted material movement in automated warehouses.”

4. Wide Temperature Operation for Diverse AGV Climates

“Engineered for industrial versatility:
  • -10~60℃ Range: Powers AGVs in cold storage warehouses (-10℃) and hot manufacturing floors (60℃), ensuring automation continuity in temperature-variable settings.”

5. Precision BMS for AGV Reliability

“Integrated BMS with CAN/RS485:
  • Real-Time Monitoring: Tracks voltage, current, and temperature with ±5% SOC accuracy, enabling AGV control systems to schedule charging and avoid unexpected shutdowns.
  • Multi-Layer Protection: Shields against overcharge, over-discharge, and short circuits—critical for AGVs operating in dense, high-stakes environments.”

Application Scenarios

1. Warehouse AGVs in E-Commerce & Retail

“Pallet & Carton Automation: Powers AGVs that move inventory in e-commerce warehouses. The 48V 18Ah LiFePO4 Battery for AGV’s 18Ah capacity supports full-shift operations, while LFP’s safety ensures reliability in narrow-aisle layouts.”

2. Factory Material AGVs in Manufacturing

“Workstation-to-Workstation Transport: Supplies energy for AGVs delivering raw materials and finished goods on production lines. Its 30A discharge handles heavy loads, and dual communication integrates with factory MES systems for workflow synchronization.”

3. Cold-Chain AGVs in Pharmaceutical & Food Logistics

“Temperature-Controlled Transport: Powers AGVs in -10℃ cold storage warehouses, with LFP’s stability ensuring consistent performance in freezing environments. CAN/RS485 communication enables real-time monitoring of battery status in temperature-sensitive logistics operations.”
