24kW High Power Battery Charger
The ADY6845 24kW high power battery charger delivers 48V nominal output, 400A current and a 20–100V range, helping high-utilization equipment reduce charging time and improve operational availability.
Reduce Charging Downtime and Power Loss
The 24kW high power battery charger reaches up to 93% peak efficiency with ±1% voltage and ±2% current regulation. Stable conversion supports predictable charging performance and helps control energy losses in demanding daily operations.
48V 400A Heavy-Duty Charging
This 48V 400A battery charger uses 380/480VAC three-phase input, fixed installation and air cooling. The high power industrial charger is suited to charging sites where high current, thermal management and reliability are key procurement concerns.
Core Specifications
| Parameter | Specification |
|---|---|
| Model | ADY6845 |
| Output Power | 24kW |
| Rated Output Voltage | 48V |
| Output Voltage Range | 20–100V |
| Rated Output Current | 400A |
| AC Input | 380/480VAC, 3-phase (323–530V) |
| Rated Input Current | 36A |
| Input Frequency | 47–63Hz |
| Peak Efficiency | Up to 93% |
| Voltage / Current Regulation | ±1% / ±2% |
| Communication | RS485, RS232, CAN, optional WiFi |
| Cooling | Air cooling |
| Operating Temperature | -20°C to +70°C; derating above 50°C |
| MTBF | >80,000 hours |
| Dimensions | 535 × 360 × 630 mm |
| Weight | 80 ± 2 kg |
| Application Scenarios | Electric forklifts, AGV/AMR systems, material-handling equipment, low-speed electric vehicles, construction machinery, aerial work platforms, agricultural equipment, industrial cleaning equipment and other electric mobility systems |
Smart Control and Safety Integration
RS485, RS232, CAN and optional WiFi simplify BMS, monitoring and fleet-system connectivity. The high power battery charger also provides IP21 protection and multiple electrical safeguards to reduce integration and downtime risk.
Multi-Application Industrial Charging
This industrial battery charger supports electric forklifts, AGV/AMR, industrial vehicles, construction machinery, aerial work platforms, agricultural equipment and cleaning systems. It is compatible with traction lithium batteries, lead-acid batteries and supercapacitors.
From Battery Matching to Deployment
Match the 24kW high power battery charger to battery voltage, charging current, communication protocol and operating conditions before deployment. Structured validation and integration planning help reduce specification errors and improve project reliability.
