Home - Product - Robot Battery - AGV/AMR Robot Battery - 48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS
48V 50Ah LiFePO4 Battery
48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS
48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS
48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS
48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS
48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS

48V 50Ah LiFePO4 Battery for AGV with RS485 CAN BMS

Category

48V 50Ah LiFePO4 Battery for AGV delivers 51.2V nominal power, 50A charge/discharge, RS485 communication, and -10~60℃ operation—ideal for forklift AGVs, traction robots, and warehouse transporters.

  • Nominal Voltage：48V
  • Rated Capacity：50Ah
  • Actual Voltage：51.2V
  • Charging Voltage：58.4V
  • Minimum Discharge Voltage：43.2V
  • Operating Temperature：-10～60℃
  • Dimension：390mm(L)*230mm(W)*140mm(H)
  • Communication Interface：RS485, CAN
  • Weight: ~20.2Kg

For More Robot Battery Solution Service, please Contact Us for details!

Quote Now
Send Email

48V 50Ah LiFePO4 Battery for AGV: Industrial-Grade Power for Automated Guided Vehicles

Product Introduction

Engineered as a 48V 50Ah LiFePO4 Battery for AGV, this lithium iron phosphate solution is purpose-built for automated guided vehicles in industrial logistics and manufacturing. Featuring a nominal voltage of 51.2V (48V class), 50Ah capacity, and integrated RS485 communication, this AGV-Specific LiFePO4 Battery 48V 50Ah combines LiFePO4’s inherent safety with industrial-grade durability. Unlike standard batteries, it supports 50A continuous charge/discharge, withstands -10~60℃ temperature extremes, and enables real-time fleet monitoring—making it the reliable power source for forklift AGVs, traction robots, and warehouse automation systems.

Technical Specifications

Table: 48V 50Ah LiFePO4 Battery for AGV Core Parameters

Parameter Details
Chemistry LiFePO4
Nominal Voltage (Class) 48V (51.2V Nominal)
Rated Capacity 50Ah
Charging Voltage 58.4V (Configurable)
Charging Current 50A (Continuous, 23℃)
Discharge Current 50A (Continuous, 23℃)
Discharge Cut-off Voltage 43.2V (Configurable)
Weight ~20.2Kg (Actual Product Basis)
Dimensions (L×W×H) 390mm×230mm×140mm
Operating Temperature -10~60℃
Storage Temperature -20~70℃
Communication RS485 (For AGV Fleet Monitoring)
Protection Features Overcharge, Over-discharge, Overcurrent, Over Temperature, Cell Balancing
Application Forklift AGVs, Traction AGVs, Warehouse Transporters, Manufacturing Automation Robots

Core Advantages of 48V 50Ah LiFePO4 Battery for AGV

1. LiFePO4 Safety & Longevity for AGV Operations

“The 48V 50Ah LiFePO4 Battery for AGV leverages lithium iron phosphate chemistry:
  • Eliminates thermal runaway risks, ensuring safety in high-traffic warehouse AGV fleets and collaborative manufacturing environments.
  • ≥2000 Cycle Life (80% Retention): Outlasts lead-acid batteries by 5-6 times, reducing AGV fleet maintenance costs by 60% over 5 years.”

2. RS485-Driven Smart AGV Fleet Management

“Integrated RS485 communication enables:
  • Real-time transmission of battery SOC, voltage, temperature, and health data to AGV control systems. Fleet managers can monitor 100+ AGVs simultaneously, preventing unexpected shutdowns during critical logistics or manufacturing tasks.
  • Customizable alerts for low battery, overcurrent, or overheating—critical for maintaining 99.9% uptime in automated material handling operations.”

3. 50A High-Power Charge/Discharge for AGV Agility

“Supports 50A continuous charge/discharge:
  • Powers forklift AGVs lifting 2000+ kg loads and traction AGVs towing heavy cargo trains, maintaining stable 51.2V output during peak load.
  • Enables 1-hour fast charging (50A charge current), reducing AGV downtime by 75% compared to standard lead-acid solutions.”

4. Wide Temperature Adaptability for Diverse Industrial Climates

“Engineered for all-weather AGV operations:
  • -10~60℃ Operating Range: Powers AGVs in cold storage warehouses (-10℃) and hot manufacturing plants (60℃), ensuring uninterrupted automation in temperature-variable industrial settings.
  • Passive Natural Cooling: Reliable heat dissipation for sustained 50A discharge, even in high-demand AGV workflows.”

Application Scenarios

1. Forklift AGVs in Warehousing & Logistics

“Pallet Handling & Inventory Management: The 48V 50Ah LiFePO4 Battery for AGV powers forklift AGVs moving 2000+ kg pallets across 100,000+ sqm warehouses. RS485 integration lets managers track battery health of 50+ AGVs, optimizing charging schedules to avoid peak-hour downtime.”

2. Traction AGVs in Manufacturing

“Material Transport in Factories: Supplies energy for traction AGVs towing raw materials and finished goods between production lines. Its 50A discharge handles heavy loads, while -10℃ operation enables use in cold-component manufacturing zones.”

3. Automated Warehouse Transporters

“Parcel Sorting & Distribution: Energizes AGVs sorting 10,000+ parcels daily. The battery’s 2000+ cycle life and low maintenance make it ideal for 24/7 e-commerce warehouse operations.”
